SHAPE‑THIN screenshot
SOFTWARE :SHAPE‑THIN
DEVELOPER :Dlubal Software
VERSION :9.02
PLATFORM :Windows
FILE SIZE :658.24 MB
LICENSE :Trial
DOWNLOADS :UserDownloads:477
SHAPE‑THIN Description

SHAPE-THIN provides the option of interface with RFEM and RSTAB: SHAPE-THIN cross-sections are available in the library of the FEA or frame analysis software, and vice versa, it is possible to import and design the internal forces from RFEM and RSTAB in SHAPE-THIN.

The structural data can be entered graphically, in tables, or by means of a DXF file.

Features

  • Modeling of the cross-section via elements, sections, arcs and point elements
  • Expandable library of material properties, yield strengths, and limit stresses
  • Section properties of open, closed or non-connected cross-sections
  • Effective properties of cross-sections consisting of different materials
  • Stress analysis including design of primary and secondary torsion
  • Check of (c/t) ratios
  • Effective cross-sections according to
  1. EN 1993-1-5:2006
  2. EN 1999-1-1:2007
  3. DIN 18800-2:1990-11
  • Classification according to
  1. EN 1993-1-1:2005
  2. EN 1999-1-1:2007
  • Interface with MS Excel to import and export tables
  • Printout report with option to print reduced report

* SHAPE‑THIN download link provides trial version of the software.
